‍Acceleration sensor for Z direction

Range maximum:

± 50 g

Frequency band:

0 ÷ 15 kHz

Noise level:

up to 25 μg/√Hz for ± 50 g range

Acceleration sensor for X, Y direction

Range maximum:

± 16 g

Frequency band:

0 ÷ 6.4 kHz

Noise level:

up to 75 μg/√Hz for ± 2 g range

Wireless communication interface

Standard:

IEEE 802.11 b/g/n Wi-Fi, WPA2

Frequency range:

2.4 to 2.4835 GHz

Transmit power:

19.5 dBm@11b, 16.5 dBm@11g, 15.5 dBm@11n

Working and storage conditions

Range:

up to 15 meters

Battery life in standby:

8 hours

Battery life while measuring:

3 hours

Operating Temperature:

-10 to +70°C

Humidity:

10 – 100% RH

Degree of protection:

IP67, dustproof housing, resistant to immersion in water

Dimensions and weight

Dimension:

40 x 42 x 27 mm (WxHxT)

Weight:

110 g

‍

‍
